| Parameters | Unit | Symbol | Min | Typ | Max |
| Working mode | ----- | ----- | ----- | APC | ----- |
| Operating Wavelength | nm | λc | 1528 | 1550 | 1564 |
| Output Power | dBm | Po | ----- | ----- | 23 |
| Input Power | dBm | Pi | -35 | ----- | 8 |
| Noise Figure | dB | NF | ----- | 4.5 | 6 |
| Power/Gain Stability | dB | ΔPo | ----- | ±0.05 | ±0.1 |
| Input Isolation | dB | ISOi | 30 | ----- | ----- |
| Output Isolation | dB | ISOo | 30 | ----- | ----- |
| Return loss | dB | RL | ----- | ----- | -45 |
| PDG | dB | PDG | ----- | ----- | 0.3 |
| PMD | ps | PMD | ----- | ----- | 0.5 |
| Consumption | W | P | ----- | ----- | 10 |
一.OEM and ODM
OEM/ODM order is available.
Guarantee
We promise all the advertised optical transceivers are brand new
with new components and parts and absolutely never use old and
refurbished materials. All the optical transceivers have been
through functional test and aging test. We provide 3 years warranty
for all the optical transceivers from the date of shipment.
What we supply
We supply all kinds of compatible optical transceiver modules,
including SFP, GBIC, SFP+, XENPAK, X2 , XFP, BIDI,CWDM,DWDM and
other special transceiver modules. Our products are compatible with
most of brands. If more details, please contact us.
FAQ
Q:Do you sell second-hand products?
A:No.All our products are brand new,we never use second-hand
components.
Q:What payment terms do you accept?
A:T/T,Paypal,Western Union are acceptable.
Q:What are the shipping ways can you offer?
A:Our usual shipping ways are DHL,FedEX,TNT,UPS,EMS etc.It will take
3-7days.
Q:Do your products come with warranty?
A:Yes,We provide 3 years warranty for all our products from the date
of shipment.
Q:What devices can your products compatible with?
A:Our products are compatible with Mainstream switches.
Q:How to place an order?
A:1>Order details confirmed,please tell us the model and quantity
you need.
2>Proforma Invoice confirmed, the order will be arranged upon
receipt of your payment.
3>Confirm and ship the goods, then tracking number will be sent
to you promptly.
4>We will help to track your goods until you receive them
safely.
