SFP Transceiver 1.25G WDM Module 40KM LC 1310nm(tx)/1490nm(rx) is compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). The transceiver consists of five sections: the LD driver, the limiting amplifier, the digital diagnostic monitor, the DFB laser and the PIN photo-detector. The module data link up to 40KM in 9/125um single mode fiber.

Features:

• Up to 1.25Gb/s data links, Up to 40KM on 9/125µm SMF
• FP laser transmitter for 1310/1550nm DFB laser transmitter for 1550/1310nm
• PIN photo-detector
• BIDI SC/UPC type pluggable optical interface
• Metal enclosure, for lower EMI
• RoHS compliant and lead-free
• Compliant with SFF-8472,Support Digital Diagnostic Monitoring interface
• Single +3.3V power supply
• Case operating temperature: Commercial: 0°C to +70°C, Extended: -10°C to +80°C, Industrial: -40°C to +85°C

The DDM SC 40KM 1.25G BIDI Module SFP 1310nm(tx)/1490nm(rx) optical output can be disabled by a TTL logic high-level input of Tx Disable, and the system also can disable the module via I2C. Tx Fault is provided to indicate that degradation of the laser. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver or the link status with partner. The system can also get the LOS (or Link)/Disable/Fault information via I2C.

Every sfp bidi transceiver module is individually tested on full range of Hilink equipments, walks through the testing challenges and 100% compatibility.

• Switch to Switch Interface
• Gigabit Ethernet
• Switched Backplane Applications
• Router/Server Interface
• Other Optical Links

Package of DDM SC 40KM 1.25G BIDI Module SFP 1310nm(tx)/1550nm(rx): 10 units in a carton box with visual plastic window, which has been labelled and marked by Hilink as default. Customized label or package solutions are available as request.
