    Multi Mode X2 Transceiver Module 300m X2-10GBASE-SR With SC Connector

    Ask Lasest Price
    Brand Name : HILINK
    Model Number : X2-10G-SR
    Certification : CE FCC Rohs
    Payment Terms : T/T, Western Union, L/C, T/T, Western Union, AliExpress , Alipay ,etc.
    Supply Ability : 1000pcs/ month
    Delivery Time : 2-5 days
    Price : Negotiable
    • Product Details
    • Company Profile

    Multi Mode X2 Transceiver Module 300m X2-10GBASE-SR With SC Connector

    Multi Mode X2 Transceiver Module 300m X2-10GBASE-SR With SC Connector

    100% compatibility: Cisco, Huawei, Ciena, H3C, HP, Extreme, Foundry, Brocade, D-link, Alcatel, Riverstone, Enterasys, Netgear, Nortel, Juniper, Ruijie, Zyxel, etc.


    FEATURES:

    Series NumberHL - X2 - 10G - SRVendor NameHiLink
    Power supply

    +3.3V, APS(+1.2V)

    Max Data Rate

    10.3125Gbps

    Wavelength850nmOptical ComponentsVCSEL at 850nm laser transmitter
    InterfaceSC duplexMax Cable Distance300m
    Cable TypeMMFDOM SupportYes
    TX Power-3 to - 1dBmReceiver Sensitivity- 11.1 to -7.5dBm
    Commercial Temperature0 to 70°C (32 to 158°F)Power dissipation1.7- 2.4W

    APPLICATION :

    • 10GE Ethernet switches and routers
    • 10GE Storage
    • 10GE Core-routers
    • Other 10Gbps Ethernet Transmission System

    XAUI I/O CHARACTERISTICS :


    ParameterSymbolMin.Typ.Max.UnitNote
    XAUI Date RateDR3.125Gb/s
    XAUI Baud Rate Tolerance-100+100ppmRelative Tolerance
    Differential Input Voltage Swing2201600mv

    8B/10B Coded Input Signal

    Differential Output Voltage Swing8001600mVp-p

    RLOAD = 100Ω ± 5%

    Differential Input Impedance80100120
    Total Output JitterTJXAUI0.35UI

    no pre-equalization

    Total Deterministic Output JitterDJXAUI0.17UI

    no pre-equalization


    PRODUCT PICTURES :


    Multi Mode X2 Transceiver Module 300m X2-10GBASE-SR With SC Connector

    GUARANTEE:

    1. We promise all the advertised optical transceivers are brand new with new components and parts and absolutely never use old and refurbished materials.
    2. If there is compatibility problem or any quality problem, you can return the goods to us and have a replacement or refund.
    3. All the optical transceivers have been through functional test and aging test.
    4. We provide 3 years warranty for all the optical transceivers from the date of shipment.

    PACKAGE & SHIPMENT:

    International Express:

    DHL, FedEx,EMS,TNT, UPS and so on. It takes 3-7 days.
