    1.25G 20KM Network SFP Transceiver Module Fiber Optic LC Connector GLC-LH-SM

    Ask Lasest Price
    Brand Name : HILINK
    Model Number : HLSP3112L-CD20
    Certification : CE FCC Rohs
    Payment Terms : T/T, Western Union
    Supply Ability : 10000pcs/ week
    Delivery Time : 1-3 days
    Price : Negotiable
    • Product Details
    • Company Profile

    1.25G 20KM Network SFP Transceiver Module Fiber Optic LC Connector GLC-LH-SM

    1.25G 20KM Network SFP Transceiver Module Fiber Optic LC Connector GLC-LH-SM


    Features

    • Data-rate of 1.25Gbps/1.063Gbps operation
    • 20km with 9/125 µm SMF
    • Hot-pluggable SFP footprint duplex LC connector Interface
    • Class 1 FDA and IEC60825-1 Laser Safety Compliant
    • Compatible with SFP MSA
    • Compatible with SFF-8472
    • +3.3V single power supply and TTL Logic Interface
    • Average Output Power: -8 ~-4 dBm
    • Receiver Sensitivity: -22dBm
    • Extended temperature range (EXT): -5 to 85°C
    • Built-in Digital Diagnostic Function

    Applications

    • Gigabit Ethernet
    • Fiber Channel Switch Infrastructur
    • Other optical transmission systems

    STANDARD

    • SFP MSA (Version Sept.14 2000) compliant
    • SFF-8472 (Rev 9.3, Aug. 2002) Digital Diagnostic Monitoring Interface for Optical Transceivers compliant
    • IEEE 802.3z compliant
    • ANSI specifications for Fiber Channel compliant
    • Telcordia GR-468-CORE compliant

    Specifications:


    P/NGLC-LH-SMD / SFP-GEL
    Datarate1.25G
    Distance20KM
    Wavelength1310nm
    TransmitterFP
    ReceiverPIN
    MediaSMF
    DDM/DOMYES
    ConnectorLC
    ApplicationGE
    Operating Temperature-10℃~ +85℃
    Voltage Supply3.3V
    CertificationCE/FCC/RoHS/TUV/UL
    Brand

    Neutral, and OEM

    Package Dimensions

    1000base-lx high performance 1310nm 20km 1.25g sfp


    Absolute Maximum Ratings


    ParameterSymbolUnitMinMax
    Storage Temperature RangeTs-40+85
    Relative HumidityRH%595
    Power Supply VoltageVccV-0.5+4

    Recommended Operating Conditions

    ParameterSymbolUnitMinTypMax
    Storage Temperature RangeTs-1070
    Power Supply VoltageVccV3.1353.465
    Data RateGb/s-1.25-

    Technical Specification


    ParameterSymbolUnitMinTypMaxNotes
    Electrical Characteristics
    Supply Current(TX+RX)IccmA300
    Single Ended Data Input SwingmV1501100
    Single Ended Data Output SwingmV300600
    TX_fault/LOS output(TTL)VohV2.0Vcc
    VolV00.8
    TX_disable input(TTL)VohV2.0Vcc
    VolV00.8
