    60km SFP+ Bidirectional Fiber Optic Transceiver Module CE RoHS Certification

    Ask Lasest Price
    Brand Name : HILINK
    Model Number : HL-10BS-60
    Certification : CE FCC Rohs
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 5000pairs/week
    Delivery Time : 1-4 working days
    Price : Negotiable
    • Product Details
    • Company Profile

    60km SFP+ Bidirectional Fiber Optic Transceiver Module CE RoHS Certification

    60km SFP+ Bidirectional Fiber Optic Transceiver Module CE RoHS Certification



    Single Core WDM Module DDM/DOM 60G 1270nm/1330nm 60km BiDi SFP+ LC

    10G BiDi SFP+ is specifically designed for the high performance integrated duplex data transmission over single mode optical fiber.

    This transceiver module is compliant with Enhanced Small Form Factor Pluggable Module SFP+ Multisource Agreement(SFF8431). This transceiver type is specifically optimized for transport of serial data at 10.3125Gbps.


    Features:

    10Gbps Data transfer rate
    1270nm DFB/1330nm DFB transmitter
    1Pair Tx1270nm/Rx1330nm and Tx1330nm/Rx1270nm BiDi SFP
    Distance up to 60km
    Single 3.3V Power Supply and TTL Logic Interface
    Hot-Pluggable SFP
    Simplex LC Connector
    Compliant with SFP MSA
    Digital Diagnostic Monitoring
    Operating Temperature Standard: 0~70℃
    Applications:
    Fiber Channel Links
    10giga Ethernet network
    WDM System

    Specifications:


    P/NSFP-WDMXX-R60
    Datarate10G/ps
    Wavelenth1330nm/1270nm
    Distance60KM
    TransmitterDFB
    ReceiverAPD
    Mode TypeSMF
    DDM/DOMYES
    ConnectorLC Simplex
    ApplicationWDM 10G Ethernet/ 2x 4x 8x FC
    Operating Temperature0℃~ +70℃
    Voltage Supply3.3V
    CertificationCE/FCC/RoHS/
    Brand

    Hilink , CISCO OEM

    10G SFP+ BiDiSFP+ BiDi 10kmSFP+ BiDi 10km 1270nm/1330nm LC
    SFP+ BiDi 20kmSFP+ BiDi 20km 1270nm/1330nm LC
    SFP+ BiDi 40kmSFP+ BiDi 20km 1270nm/1330nm LC
    SFP+ BiDi 60kmSFP+ BiDi 60km 1270nm/1330nm LC
    SFP+ BiDi 80kmSFP+ BiDi 80km 1490nm/1550nm LC

    100% compatibility: Cisco, Huawei, Ciena, H3C, HP, Extreme, Foundry, Brocade, D-link, Alcatel, Riverstone, Enterasys, Netgear, Nortel, Juniper, Ruijie, Zyxel, etc.


    Our Service:

    1. Contact our sales for more details to confirm your order.
    2. Short lead time after confirmation.

    3. We deliver goods by international Express.

    4. Quick response for customers' feedback and other questions.


    Shipment & Payment
    1. International Express: DHL, Fedex, UPS, EMS, UPS, TNT and etc.
    2. Payment: T/T, Western Union, Paypal and so on.


    Technician support:

    We support technical guide to solve malfunction or substitute components, and provide the project of related networking configuration.
    After-sales service
    We have after service for 24 hours, promises to supply technical service or guide in anytime.
    Our co-workers will be response clients's requirement in 12 hours after emergency happened.


    Packing Details: Static bag, Plastic PVC Pack, Retail box, Technical box, or customized
