    Hilink fiber optic module 10G 20KM CWDM SFP+ Optical Transceiver module

    Ask Lasest Price
    Brand Name : HILINK
    Model Number : CWDM-SFP+1290nm
    Certification : CE FCC Rohs
    Payment Terms : T/T, Western Union
    Supply Ability : 100PCS Per Day
    Delivery Time : 3-5 Working Days
    Price : Negotiable
    • Product Details
    • Company Profile

    Hilink fiber optic module 10G 20KM CWDM SFP+ Optical Transceiver module

    Hilink fiber optic module 10G 20KM 30KM CWDM SFP+ Optical Transceiver

    Full 18 channels as cwdm available for 1270nm 1290nm 1310nm 1330nm 1350nm 1370nm 1390nm

    1410nm 1430nm 1450nm 1470nm ,1490nm 1510nm 1530nm 1550nm 1570nm 1590nm 1610nm


    Product Details

    • Hot-pluggable SFP+ footprint MSA
    • Up to 10.3Gb/s bi-directional data links
    • Power dissipation < 1.5W
    • RoHS-6 compliant (lead-free)
    • Commercial temperature range -5°C to 75°C
    • Single 3.3V power supply
    • link length up to 20km on 9/125mm SMF at 10 Gb/S
    • CWDM DFB laser transmitter
    • Receiver limiting electrical interface
    • Duplex LC connector
    • Built-in digital diagnostic functions DDM

    Item No.CW-SFP10G-29LVendor NameHilink
    Form TypeSFP+Max Data Rate10Gbps
    WavelengthCWDMMax Cable Distance10KM
    InterfaceLC duplexOptical ComponentsDFB PIN
    Cable TypeSMFDOM SupportYes
    TX Power-5~0dBmReceiver Sensitivity<-11dBm
    Commercial Temperature Range0 to 70°C (32 to 158°F)HTS-Harmonized Code851770600



    We are not only the provider of cwdm sfp , we are also the provider of cwdm solutions
